MECHANISM
TECHICAL DESCRIPTION
01
Channel
Dual, isolated between channels
02
Dimensions
107x62x27mm
03
Weight
Approximately 150 grams, battery included
04
Amplitude
Adjustable 0-60mA peak into 500 ohm load each channel, constant current
05
Carrier Frequency 4000Hz, Fixed (CH1)
06
Modulating Frequency 4-160bps, Adjustable (CH2)
07
IF Frequency Modes 9 modes, 1 constant mode, 5 frequency shift modes, 3 auto sweep Modes
08
Constant Mode 4-160bps, Adjustable
09
Auto Sweep
4-45 bps
80-145 bps
4-SET bps
10
Frequency Shift
Five modes,
1/1 abrupt shift
6/6 abrupt shift
6/6 ramped
10/10 abrupt shift
10/10 ramped
bps adjustable
11
Sweep Time 15 seconds
12
Frequency Shift
Percent
Frequency shifts from 30% below the set frequency to 60% above and
then return to 30% below the set frequency.
13
Output Configuration Quad polar (4 electrodes)
14
Wave form Symmetrical Balanced Sine Wave
15
Interference
Pulse Frequency
4-160 bps, Adjustable, 4 bps/step
16
Pulse Duration 125 μs maximum
17
Patient Compliance Meter Display total treatment time
18 Lock Prevents the patient from accidentally changing any of the set parameters
19 Timer 15, 30 minute selectable
